TORQUE RESISTANT BUSHING KBDR1-12

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-12 (R069601200) is a high-quality component designed for self-supporting, torsionally stiff guides with a single shaft application. This torque-resistant linear bushing standard features ball guide grooves and comes without a seal or shaft, ensuring ease of integration into various systems. The KBDR1-12 is set to zero clearance with an adjusting screw and secured with a steel lock nut, providing precise movement control. Constructed with hardened steel bearing plates and balls made of rolling bearing steel, the bushing offers robust performance and durability. Its ball retainer and outer sleeve are made from either PA or POM materials, contributing to the component's strength and longevity. The dynamic torsional moment load capacity Mt ensures that it can handle varying levels of torque effectively. With a size N footprint, the KBDR1-12 provides a static load rating C that reflects minimal values due to the potential variability in loading direction. It has been designed to operate within an ambient temperature range of -...°C to ...°C, accommodating various working environments. Additionally, its maximum permissible linear speed vmax and max acceleration amax specifications cater to applications requiring high-speed motion. The closed format of the Bosch Rexroth linear bushing ensures that it maintains its structural integrity during operation. Its dynamic load capacity C is indicative of the product's ability to withstand operational stresses over time. Weighing in at . kg, this model strikes a balance between strength and ease of handling for installation purposes. Overall, the Bosch Rexroth TORQUE RESIST.BUSH KBDR1-12 (R069601200) is an essential component for creating reliable linear motion systems where torsional resistance is crucial. It provides precise control and robust performance for various applications requiring single-shaft guides.
