TORQUE-RESISTANT LINEAR BUSHING KBDRC2-50

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDRC2-50 (R072035000) is a torqueresistant LB compact linear bushing designed for self-supporting, torsionally stiff guides with only one shaft. It features a ball guide groove system for precision and is made without a seal, making it suitable for applications where sealing is not required. The linear bushing and shaft are engineered to provide zero clearance thanks to an adjusting screw that comes preset, ensuring high precision and reduced play in the system. This model is constructed with a ball retainer and outer sleeve made of either PA or POM, depending on the specific application requirements. Its precision steel shaft is designed for ball guide grooves, accommodating shaft diameters from d mm upwards, with two ball guide grooves introduced from larger diameter sizes. The hardened steel bearing plates and balls crafted from rolling bearing steel contribute to the unit's durability and consistent performance. The dynamic torsional moment load capacity Mt of the KBDRC2-50 ensures it can handle significant loads while maintaining stability. The product's static load rating C0 and dynamic load capacity C reflect its ability to withstand minimal values of loading in various directions. With a maximum permissible linear speed vmax and an ambient temperature range from -30°C to +80°C, this linear bushing can operate effectively in diverse environments. Weighing approximately 0.5 kg, the compact size N of the KBDRC2-50 does not compromise its robustness or capability to support dynamic loads efficiently. This model is part of Bosch Rexroth's series of torqueresistant compact products within their Productgroup ID and comes complete with a steel lock nut for secure assembly. Overall, the Bosch Rexroth TORQUE RESIST.BUSH KBDRC2-50 (R072035000) provides reliable guidance in applications requiring precise movement control with resistance to torsional forces, making it an optimal choice for sophisticated mechanical systems requiring high-performance linear motion solutions.
