TORQUE-RESISTANT LINEAR BUSHING KBDRC1-12

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDRC1-12 (R072001200) is a high-precision component designed for self-supporting, torsionally stiff linear guides with a single shaft. This torqueresistant compact linear bushing is engineered without a seal and does not include a shaft, allowing for customization based on specific application requirements. The product features ball guide grooves and is ideal for applications requiring precise linear motion with minimal clearance due to its adjustable screw that comes set to zero clearance. Constructed with durability in mind, the bushing includes a ball retainer and outer sleeve made of either PA or POM, while the precision steel shaft is designed with a ball guide groove for shaft diameters. For increased stability, two ball guide grooves are included from certain shaft diameters. The bearing plates are made of hardened steel, ensuring longevity under dynamic conditions. Moreover, the balls themselves are crafted from high-quality rolling bearing steel. This model boasts a dynamic load capacity (C) and static load rating (C0), which are minimum values due to the variable nature of loading directions in different applications. It also has an impressive dynamic torsional moment load capacity (Mt). The Bosch Rexroth TORQUE RESIST.BUSH KBDRC1-12 operates efficiently within an ambient temperature range of -30°C to +80°C and can handle maximum accelerations as well as high linear speeds. With its closed format design, this linear bushing ensures smooth operation and is suitable for various filtering systems for linear bushings and shafts. The unit has a weight of 0.18 kg and comes equipped with hardened steel adjusting screws along with a reliable steel lock nut. Its outer diameter measures D1, facilitating integration into diverse mechanical setups where robustness and precision are essential.
