LOCATING RING D=7/5 ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LOCATING RING (R039660547) is a precision mechanical accessory designed to facilitate the mounting of customer attachments to frames in linear axes systems. This centering ring falls under the product group ID for mechanical accessories and specifically within the category of centering rings Size E. It is constructed from durable steel, ensuring longevity and resistance to wear under operational conditions. The LOCATING RING boasts an outer diameter designated as Size D, which corresponds to a nominal size with a tolerance defined by a C prefix and suffix. This tolerance ensures that the ring fits precisely into its intended position, providing a positive-locking connection that can be reproduced accurately during multiple installations. The ring's size H and weight are optimized for its function without compromising on strength or stability. Designed for ease of use, this locating ring serves as both a positioning aid and for creating a secure lock when attaching components to the frame. The positive-locking feature of this Bosch Rexroth LOCATING RING means that once it is in place, it maintains its position reliably, contributing to the overall integrity and efficiency of the linear motion system it is part of. Its design ensures good reproducibility, which is essential for consistent performance in applications where precision alignment is critical. Overall, the Bosch Rexroth LOCATING RING (R039660547) represents an essential component for users requiring precise mounting solutions within their linear motion systems. Its robust construction paired with meticulous design specifications makes it an indispensable part of ensuring accurate assembly and operation in various applications where linear axes are utilized.
