LOCATING RING D=9/7 ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LOCATING RING (R039660549) is a mechanical accessory designed to facilitate precise positioning and secure locking for customer attachments on linear axes. As part of the product group ID for centering rings, this particular model is crafted from durable steel, ensuring robust performance and longevity. The locating ring's primary function is to create a positive-locking connection with excellent reproducibility, which is essential for maintaining accuracy in various applications. With an outer diameter designated as size E and a tolerance categorized under the C prefix, this component adheres to precise manufacturing standards. It has been engineered with specific size dimensions, including a nominal size that corresponds to its application requirements. The weight of the ring is kept minimal to not add significant mass to the assembly it becomes a part of. Additionally, the tolerance for the outer diameter falls under the D prefix, ensuring that it meets exact specifications for fitting and operation. Size H of the locating ring further specifies its dimensions, contributing to its compatibility with corresponding equipment. This Bosch Rexroth LOCATING RING is essential in systems where accurate alignment and secure mounting are critical. Its steel construction offers reliability in various settings, making it a valuable component in ensuring the stability and precision of linear motion assemblies.
