LIFT-ROTATE UNIT HD2 B240*LT160 180 40

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2 B240*LT160 180 40 (3842525855) is a precision-engineered component designed to facilitate the orientation and positioning of workpiece pallets on conveyor systems. This unit is capable of lifting and rotating workpieces with a turning angle on the Z axis of either 90° or 180°, depending on the application requirements. The lift-rotate unit can elevate workpiece pallets by either 40 mm or 90 mm above the transportation level, which allows for flexibility in handling various sizes and configurations of workpieces. The HD2 B240*LT160 model is particularly suitable for use in systems where maintaining a consistent orientation of the pallet is essential, such as in automated manufacturing lines where each side of the product may need to be accessible for different processes. The option to lift by 40 mm is designed for scenarios where direct interaction with the conveyor section is needed, while the 90 mm lift version accommodates side-mounted components like identification tags or data storage modules that may protrude from the pallet. This unit's robust design ensures that it can handle a maximum permitted total mass moment of inertia of up to 0.65 kgm^2, making it a reliable choice for handling substantial loads without requiring additional force during operation. The HD2 lift rotate unit's functionality streamlines production processes by ensuring smooth transitions and precise positioning, enhancing overall efficiency and throughput in material handling applications.
