CHANGEOVER SET 160X160HD2-LS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CHANGEOVER SET (3842563535) is a highly specialized component designed for precise and efficient handling of workpiece pallets within automated systems. This set offers the flexibility of turning angles on the Z-axis, enabling customization to meet specific application requirements. It is particularly adept at manipulating the rotational direction of the HD2-LS, which can be individually actuated for each workpiece pallet. With two options for lift heights—either mm or mm above transportation level—this changeover set caters to different operational needs. The mm lift version is optimized for rotating workpiece pallets directly above the conveyor section, ensuring seamless transitions during the manufacturing process. In scenarios where side-mounted components such as identification and data storage modules are present on the workpiece pallet, the mm lift variant may be more appropriate to avoid interference with these attachments. The robust design of this changeover set can handle a maximum permitted total mass moment of inertia of . kgm², demonstrating its capability to manage substantial loads without compromising performance. It also maintains an impressive maximum permitted total mass moment of inertia at . kgm²/s², highlighting its dynamic efficiency under various operational conditions. This product falls under Productgroup ID and has a weight of . kg, indicating its substantial build quality and durability. The scope of delivery includes all necessary fastening materials for installation. However, it requires additional accessories such as a stop gate VE...,Mx and a sensor with a rated sensing range of SN mm. Notably, this sensor cannot be installed flush; it requires an offset of . mm to function correctly. In summary, the Bosch Rexroth CHANGEOVER SET 160X160HD2-LS is engineered for adaptability and precision in automated material handling systems, offering reliable performance in complex industrial environments.
