LIFT-ROTATE UNIT HD2,B240*LT240 180 90

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT-ROTATE UNIT HD2B240*LT240 180 90 HD 2, b240, l lift rotate unit_T240, DW180, h90 is a sophisticated component designed to enhance the functionality of conveyor systems by providing precise lifting and rotating actions. This unit is specifically engineered to turn workpiece pallets either 90° or 180° on the Z axis, which is critical for maintaining correct orientation during transportation on systems that lack curves. It ensures that workpieces are always facing the right direction, which can be essential for subsequent automated processes or manual operations. The lift-rotate unit comes in two variations: one with a WT lift of 40 mm and another with a WT lift of 90 mm above the transportation level. The choice between these versions depends on the specific requirements of the application. The 40 mm version is ideal for situations where workpiece pallets need to be turned directly above the conveyor section without interference from side-mounted components. In contrast, the version with a 90 mm lift is designed to accommodate workpiece pallets that have additional elements such as identification and data storage modules attached to their sides. This unit's capabilities include handling a maximum permitted total mass moment of inertia of up to 0.65 kgm², allowing it to manage a range of pallet sizes and weights efficiently. Additionally, its design permits operation without applying extra force, ensuring smooth and reliable performance in various industrial applications. The Bosch Rexroth LIFT-ROTATE UNIT HD2B240*LT240 180 90 HD 2 is an integral part of advanced automation solutions where precision and adaptability in material handling are paramount.
