PRESSURE TRANSDUCER HM 20-2X/315-C-K35-N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HM 20-2X/315-C-K35-N (R901466599) is a high-performance pressure transducer designed for dynamic pressure control in hydraulic systems. It features an analog output of 4-20 mA and can measure pressures up to 315 bar with a rapid signal rise time of less than 10 ms, enabling precise and quick response to changes in pressure. The measuring cell utilizes thin-film technology, ensuring high accuracy with less than 0.3% full-scale (FS) error and excellent non-repeatability characteristics below 0.1%. All media-contacting components are constructed from durable stainless steel, offering robust resistance against corrosive fluids. This model is equipped with a G1/4 hydraulic connection and includes a throttle element within the pressure channel to modulate fluid flow. Electrical connectivity is provided by a connector pole M12x1, A-coded, conforming to EN standards. The unit does not feature a display but ensures operational reliability through protections against overpressure, reversed polarity, overvoltage, and short circuits. With an operational temperature range broad enough to handle extreme conditions and compatibility with various hydraulic fluids such as HL, HLP, HFC types, and nitrogen up to 315 bar, it is versatile for diverse applications. The transducer also meets multiple conformity standards including CE for electromagnetic compatibility, UL for safety certification, UKCA marking for UK conformity assessed products, RoHS Directive for restriction of hazardous substances in electrical and electronic equipment, and DNV marine approval certifying its suitability for maritime applications. Its compact design has a weight of only 0.4 kg and utilizes NBR seals to maintain integrity under fluctuating pressures and temperatures.
