PRESSURE TRANSDUCER HM 20-2X/400-C-K35-N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HM 20-2X/400-C-K35-N (R901456334) is a high-performance pressure transducer designed for dynamic pressure control applications. This model boasts an analog output of 4...20 mA and operates within a pressure range of up to 400 bar. Its rapid signal rise time of less than 10 ms makes it ideal for systems requiring swift responses. The transducer features a throttle element in the pressure channel and a sturdy hydraulic connection G1/4, ensuring reliable operation. Equipped with a thin-film measuring cell, the HM 20-2X/400-C-K35-N ensures high measurement accuracy of less than ±0.5% FS and exhibits excellent overload and burst resistance. All media-contacting components are crafted from durable stainless steel, enhancing the unit's compatibility with various hydraulic fluids such as HL, HLP, HFC, and Nitrogen up to 350 bar. The device's electrical connection is facilitated through a connector pole M12x1, A-coded as per EN standards. It requires a supply voltage of 8...32 VDC and weighs approximately 0.4 kg. The seals are made from NBR to maintain integrity under different conditions. Notably, this model does not include a display but ensures operational safety with protections against reversed polarity, overvoltage, and short-circuit incidents. Its accuracy class is 0.5 with an exceptional non-repeatability of less than 0.1%. The HM 20-2X/400-C-K35-N can operate within a wide temperature range from -40 to +125°C. Additionally, it holds several conformity certifications including CE for electromagnetic compatibility, UL, UKCA, RoHS for restriction of hazardous substances, and DNV GL marine approval for variants with current output signals—validating its suitability for diverse applications including marine environments where robust performance is required under stringent conditions.
