ROLLER GUIDE RAIL CARBON STEEL RSA-025-SNS-S-MB-00

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.GUIDE RAIL CS (R180720131) is a high-precision roller guide rail designed for applications that demand superior accuracy and rigidity. This guide rail is part of the RSA-025-SNS-S-MB-00 series, which features a slimline width, standard height, and normal length configuration within the SNS size format. The rail itself is constructed from carbon steel (CS), ensuring durability and strength for various operational demands. With an accuracy class of super precision (SP), this one-piece guide rail offers exceptional guidance for linear movements. It has been engineered to provide maximum rigidity in all load directions, along with a very high torque load capacity. The hardened raceways are smoothened on all sides, contributing to the smooth operation and longevity of the system. Designed for mounting from below using fastener MB (bolting from below), this model does not include a cover strip, which allows for ease of installation and maintenance in environments where a cover is not necessary. The permissible ambient temperature range for this guide rail extends from minimum to maximum degrees Celsius; however, short-term operation outside these limits may be possible upon consultation with Bosch Rexroth. The R.GUIDE RAIL CS has a nominal weight and features a pitch T guide rail specification that supports precise alignment during installation. For optimal performance and fit, it is recommended to utilize the provided rail length formula: L = nB * T + mm, where nB represents the number of holes and T denotes the pitch. This roller guide rail system caters to demanding linear motion requirements across various applications without compromising on precision or strength. Its design adheres to DIN standards for linear guides, ensuring compatibility with standardized components and systems.
