ROLLER RUNNER BLOCK CARBON STEEL RWD-035-SNS-C3-U-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-035-SNS-C3-U-2 (R18223392X) is a high precision roller runner block designed for ultra-precise linear motion applications. This component features a slimline width, standard height, and normal length format (SNS), with a body made of unalloyed steel CS. It offers high preload (class C) and ultra precision accuracy (class UP), ensuring maximum rigidity and load capacity in all four main directions of loading. The runner block is preserved but comes without initial lubrication or attachment elements on the left or right front reference edges. The RWD-035-SNS-C3-U-2 has an overall length of . mm and boasts interchangeability with guide rails of every accuracy, facilitating versatility in assembly and maintenance. Accessories can be attached to the front, while lube nipples on all sides enable easy lubrication. Its innovative channel design minimizes lubrication requirements, while the optimized return and guideways ensure smooth, quiet operation. This model's entry zone geometry is multi-optimized with a high number of rollers to achieve low elastic deflection and precise movement. The runner block features an integrated all-around sealing as standard and can be combined with various guide rail versions without restrictions. The RSHP roller runner blocks are designed to accommodate a wide range of applications and environmental conditions without the need for special designs. Key specifications include size diameter S profiled rail systems, static load rating C0, dynamic torsional moment load capacity Mt, permissible ambient temperatures ranging from min ... max °C for short durations, friction coefficients between , ... , , and maximum permissible linear speed vmax. This model is part of product group ID . It does not come with a roller chain or self-alignment feature but is self-aligning to compensate for misalignments during installation or operation. This Bosch Rexroth roller runner block ensures reliable performance even under demanding circumstances while maintaining ease of maintenance and versatility in application.
