ROLLER RUNNER BLOCK CARBON STEEL RWD-045-SNS-C2-H-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-045-SNS-C2-H-2 (R18224232X) is a high-precision roller runner block designed for linear motion applications requiring high accuracy and rigidity. This component is part of the RSHP series, which is suitable for a wide range of applications without the need for special designs. The RWD-045-SNS-C2-H-2 model features a slimline width, normal length, and standard height format (SNS), with a body made from unalloyed steel CS. It boasts an average preload class C and high accuracy class H, ensuring medium preload and high precision respectively. The runner block has no roller chain and comes preserved but without initial lubrication or attachment elements on either front reference edge. Its straight lube connection is loosely attached for easy maintenance. The product offers high torque load capacity with equal load ratings in all four main directions and maximum rigidity due to additional screw connections on two boreholes at the center. It provides unrestricted interchangeability, as all guide rail versions can be combined with any roller runner block variant. Accessories can be mounted to both the front of the runner block and from above or below, enhancing its versatility. The innovative channel design ensures minimal lubrication quantities are needed while promoting smooth, quiet operation through optimized return and guideways for the rollers. This model also features integrated all-around sealing as standard. The dynamic load capacity C and dynamic torsional moment load capacity Mt are determined based on a 100,000 m travel as per DIN ISO standards. The product's static load rating C0, static longitudinal moment load capacity ML, friction coefficients, permissible ambient temperatures, acceleration capacities (amax), preload force specifications, maximum permissible linear speed (vmax), seal options (DS), product group ID, weight, nominal size details are meticulously engineered to ensure reliability in demanding situations. Overall, the Bosch Rexroth R.RUNNER BLOCK CS RWD-045-SNS-C2-H-2 offers exceptional precision and durability for sophisticated linear motion systems where performance cannot be compromised.
