This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
| Quick, economic installation |
| Compensates the differences in thermal expansion between machine elements made of different materials |
| Eliminates the need for keyways or other positive-locking connections |
| Connecting parts have a simple design |
| High temperature stability |
| Special sizes available on request |
| Extremely low-cost machine element |
| Resistant to various types of chemical stress |
| Fixed and secure connection of machine parts |
| Large tolerance zone with connecting parts |
| Data Sheet | Download Data Sheet |
| Productgroup ID | 17 |
| Size b | 14 |
| Material footnote | Up to 250 °C continuous temperature, short-term up to 300°C |
| Size d | 10 |
| Transferable torque footnote 1 | Observe the general technical notes and information. |
| Transferable torque footnote 2 | In case of free installation with 20% reduction, see section “Calculations” for the guideline values |
| Permissible radial load footnote 2 | Considerably smaller values are permitted for pulsating and alternating loads. Please consult us. |
| Weight | 0.0006 |
| Transferable torque | 4.2 |
| Permissible radial load | 2500 |
| Nominal size | 10 x 14 |
