TOLERANCE RING AN24X7

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN24X7 (R081002403) is a precision engineered component designed for creating fixed and secure connections between machine parts. This tolerance ring, belonging to the Type AN category, features circumferential flat edges on its outer diameter, making it suitable for use with a standard nominal shaft. Fabricated from carbon steel, it offers high temperature stability and resistance to various chemical stresses. With its large tolerance zone, the AN24X7 tolerance ring compensates for differences in thermal expansion across dissimilar materials, thus eliminating the need for keyways or other positive-locking connections. This contributes to a simpler design for connecting parts and ensures a quick and economical installation process. The product is also noted for its extremely low cost as a machine element while providing a reliable performance. The specifications of this model include a nominal size of 24x7 mm, ensuring compatibility with corresponding shaft sizes. It offers an impressive balance between transferable torque and permissible radial load, adhering to specific guideline values that are detailed in the technical notes provided by Bosch Rexroth. Special sizes of this tolerance ring can be requested to suit unique application requirements. This flexibility combined with its robust design makes the Bosch Rexroth TOLERANCE RING AN24X7 an essential component in mechanical assemblies where precision and durability are paramount.
