LINEAR-SET LSSDR1T-20-WV-500

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR1T-20-WV-500 (R109722080) is a robust linear motion system designed for precision applications requiring high torque resistance and stability against cocking loads. This linear set includes a precision steel shaft with one ball guide groove and two torque-resistant linear bushings, which are pre-set to zero clearance ex works to ensure optimal performance. The tandem ball guide grooves facilitate smooth and accurate movement, making this system suitable for various dynamic applications. Crafted from high-quality steel, the LINEAR-SET LSSDR1T-20-WV-500 is built for durability and long service life. It does not include external seals, which allows for use in environments where seals are not necessary or where custom sealing solutions are preferred. The shaft diameter 'd' and standard length comply with the specifications provided in the accompanying table, ensuring compatibility with a wide range of installations. The system's dynamic load capacity 'C' indicates minimal values since loading directions can vary, providing flexibility in application design. Its static load rating 'C' and dynamic torsional moment load capacity 'Mt' further contribute to its robustness in both static and dynamic states. The maximum permissible linear speed 'vmax' and mass 'm kg/m' are specified to assist engineers in selecting the appropriate components for their systems. Operating within a permissible ambient temperature range of -20°C to +80°C, this linear set can be deployed in diverse working conditions without compromising performance. Its outer diameter 'D', size classifications such as Size E, H, L, and weight specifications provide essential details for integration into mechanical assemblies. In summary, the Bosch Rexroth LINEAR-SET LSSDR1T-20-WV-500 offers precision movement capabilities within its defined environmental parameters, making it an excellent choice for applications where high torque resistance and stability are paramount.
