SV08-28P-0-N-230AG SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5005913 (5005913) is a solenoid-operated, 2-port, normally closed direct-acting poppet type screw-in hydraulic cartridge valve. It is specifically designed for low leakage blocking and load-holding applications. This model operates by blocking flow in both directions when de-energized, and upon energization, the poppet opens to allow bidirectional flow. Key features of this valve include a continuous-duty rated coil and a hardened seat which ensures long life and minimal leakage. The valve offers flexibility with optional coil voltages and terminations, making the cartridges voltage interchangeable. Additionally, it includes a manual override option and an optional waterproof E-Coil that is rated up to IP69K, enhancing its utility in various environments requiring robust performance standards. The compact size of the Hydraforce 5005913 allows for easy installation and compatibility with industry common cavity configurations, further simplifying integration into existing systems.
