63FLDKN0250-1X/PWR10A00-V2,2-M-S6 (2 PACK)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 63FLDKN0250-1X/PWR10A00-V2,2-M-S6 (1015303B) is a high-performance hydraulic-duplex in-line filter designed for the effective filtration of solids from hydraulic fluids and lubricating oils. This filter is specifically engineered for integration into pipeline systems, allowing for seamless operation as the filter elements can be replaced without interrupting the system's function. The duplex design ensures continuous filtration and reliability, making it an essential component in maintaining fluid cleanliness in hydraulic systems. Constructed from durable nodular cast iron, this filter boasts a robust housing material that can withstand a maximum working pressure of 63 bar and a nominal pressure rating of 63 bar. Its filtration media is made from multilayer glass fiber material designated as PWR10, providing an efficient filtration grade of 10 microns. The Hengst model features an optical indicator for easy monitoring and has a bypass cracking pressure set at 3.5 bar to ensure optimal performance under varying conditions. The filter's design includes a back mounting configuration with port specifications adhering to SAE standards, featuring a port size of 1 1/2\" - 3000 psi with the inlet positioned above the outlet. It also incorporates a ball valve change-over design for smooth switching between filters without system downtime. With its suitability for HFC and HFA fluids and compliance with DIN24550 standards, this duplex in-line filter offers versatility across various applications requiring reliable solid particle removal from fluids under high-pressure conditions. Additionally, it includes features like cyclone effect to enhance separation efficiency and standard support cage material to provide structural integrity during operation.
