400LDN1000-PWR10B00-V8,0-M-S8 (2 PACK)

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 400LDN1000-PWR10B00-V8,0-M-S8 (1015076B) is a highly efficient hydraulic-duplex in-line filter designed for the filtration of solids from hydraulic fluids and lubricating oils. This filter is specifically intended for installation in pipelines and provides the advantage of replacing filter elements without interrupting operation. The filter features a multilayer glass fiber material (PWR10), which ensures effective filtration with a grade of 10 microns. Its robust construction includes a housing made of nodular cast iron and carbon steel, making it suitable for high-pressure applications with a maximum working pressure of 400 bar. The unit is equipped with an optical indicator to monitor the operational status and has a stopcock change-over design for seamless switching. The port designation is 2\" - 6000 psi, adhering to SAE standards, and it is mounted horizontally. With its NBR seals and standard support cage material, this duplex inline filter meets DIN24550 standards and is suitable for HFC/HFA fluids. The Hengst model also features a two-parted bowl design but does not include cyclone effect or lid lifting devices, focusing on straightforward functionality in demanding environments.
