SERVOMOTOR MS2E03-D0BYN-CMSK1-NNNNN-NN

Manufacturer: Bosch Rexroth

Material #: R914000700

Model : MS2E03-D0BYN-CMSK1-NNNNN-NN

$3,651.33 USD

More are expected on February 3, 2025

Add to Cart

Status: This product is temporarily out of stock.

Qty: Delivered as early as February 3, 2025 when ordered in

SERVOMOTOR MS2E03-D0BYN-CMSK1-NNNNN-NN

Synchronous Motor MS2E (ATEX), Size 03, self-cooling

The product range of Rexroth´s servo motors combines high dynamics with compact dimensions and best energy efficiency. Rotors with low and medium inertia are available with optimum mass customization. For intelligent solutions in the Industry 4.0 environment, the motors serve as data sources. Special explosion-proof versions according to ATEX complete the extensive portfolio.

Unpacked Weight: 0.000 kg

Maximum torque Mmax 3.8 ... 120 Nm

2D CAD	Download 2D CAD
3D CAD	Download 3D CAD

Mounting hole	M4
Shaft length	23
Maximum torque	7.4
Productgroup ID	4,6
Rotor inertia	Low inertia
International protection code	IP65
Rotor inertia (with brake) value	0.000044
Shaft	Adjustment spring, with shaft seal
Motor type (with/without brake)	Holding brake, size 1
Flange size	58
Bolt circle	63
Cooling type	Self-cooling
Continuous torque (int./ext. cooling) 100k	1.15
Maximum speed	9000
Type code extension	MS2E03-D0BYN-CMSK1-NNNNN-NN
Continuous torque (int. cooling) 60k	1.15
Shaft diameter	11
Rotor inertia (without brake) value	0
Spigot	40
ctrlX configurator	https://www.boschrexroth.com/ctrlx-configurator/
EPLAN	https://ecad-configuration.boschrexroth.com/?rootpartnr=BOS.MS2E03-D0BYN-CMSK1-NNNNN-NN**&downloads=true
Weight	0.000
