ANALOG INPUT MODULE S20-AI-4-UTH

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth S20-AI-4-UTH (R911173342) is a sophisticated IO module designed to facilitate the integration and management of signals within industrial environments. This module is specifically engineered to acquire signals from conventional thermocouples, adhering to standards DIN EN 60584 and DIN 43710, as well as managing linear voltages ranging from -100 mV to +100 mV. Additionally, it can handle voltage inputs between 0 V and 10 V, which is particularly useful for monitoring heating currents through the use of a measuring transducer. Equipped with two Pt100 inputs, designated as CJ1 and CJ2, this module provides versatility by allowing each input to function either as a sensor input or an external cold junction. The S20-AI-4-UTH also boasts an innovative design that emphasizes space-saving and modularity, making it ideal for top hat rail mounting in control cabinets or field installations. Its robust mechanics are complemented by forced ventilation via an axial fan, ensuring reliable operation under various conditions. The device further simplifies usage with its intuitive assembly and installation concept while offering fast reaction times for efficient process control. Open communication standards ensure seamless integration for maximum system availability. The module also includes diagnostic and status indicators along with an electronic device nameplate for easy identification and troubleshooting. The compact form factor of the S20-AI-4-UTH combined with its high flexibility makes it a valuable component for custom machine concepts requiring precise signal acquisition and control.
