ANALOG INPUT MODULE S20-AI-4-U

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth S20-AI-4-U (R911173256) is an S IO cabinet analog input module that boasts a compact and modular design, tailored for top hat rail mounting within an S station. This particular module is capable of acquiring analog voltage signals, ensuring versatility in application by supporting both 0-10 V and 0-20 V inputs. It features a convenient conductor connection technique that allows for streamlined installation and maintenance. Equipped with four channels, the S20-AI-4-U ensures efficient signal processing and can be combined with other individually combinable modules from the same product group. This flexibility makes it an ideal choice for customized control system configurations. The innovative assembly concept emphasizes space-saving without compromising on functionality, which is essential in modern control cabinet layouts. The type code extension "SAIU" and the inclusion in Productgroup ID indicates that this module can be easily identified and integrated using the ctrlX configurator provided by Bosch Rexroth. Additionally, its lightweight design at only 0.2 kg minimizes additional load on mounting structures. For technical planning and documentation purposes, the module is also supported by EPLAN software, allowing for efficient electrical project planning. Diagnostic and status indicators are built into the device to provide immediate feedback on its operation, enhancing troubleshooting processes and reducing system downtime. In summary, the Bosch Rexroth S20-AI-4-U analog input module offers a sophisticated solution for capturing analog signals within automated systems, combining ease of use with a flexible configuration to meet various industrial requirements efficiently.
