PRESSURE SWITCH HEDE12-1X/250-2-K35-V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HEDE12-1X/250-2-K35-V (R901507474) is an advanced electronic pressure switch designed for precision monitoring and control of system pressure. This device features a user-friendly display, IOLink capability, and two switching outputs, offering a maximum operating pressure of 250 bar. The unit's ability to transmit both pressure and diagnostic values via IOLink makes it an intelligent choice for systems requiring detailed monitoring. Constructed with all stainless steel components in contact with the media, the HEDE12-1X/250-2-K35-V ensures durability and compatibility with various fluids. It boasts a high measurement accuracy of less than 1% FS and exhibits exceptional overload and burst resistance, thanks to its thin-film measuring cell. The hydraulic connection is a G-threaded throttle element in the pressure tube, which can be easily configured either through IOLink or directly via the button on the device. For electrical connections, this model uses a 4-pole M12 connector that is A-coded according to DIN EN standards. It operates on a supply voltage of 24 VDC and has a weight of approximately 0.5 kg. The seals used within are made from FKM material, ensuring reliable performance when used with hydraulic fluids like HL, HLP, HFC, or Nitrogen up to 250 bar. Additionally, the HEDE12-1X/250-2-K35-V complies with multiple conformity standards including CE for electromagnetic compatibility within the EU, UL recognition for safety standards compliance, and RoHS for restriction of hazardous substances. With its robust construction and versatile features, this electronic pressure switch is well-suited for applications requiring precise pressure management and diagnostic capabilities.
