MULTISTATION MANI. 6HSR06M-40/01D FE//Z&

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MULTISTATION MANI. 6HSR06M-40/01D FE//Z& (R901475554) is a meticulously engineered hydraulic manifold designed for vertical stacking applications. This product allows for the construction of highly compact hydraulic controls by utilizing vertically stackable sandwich plate valves alongside on-off and proportional servo valves. The manifold features a common pump and tank port P and T, with the pump line accessible from both front sides, ensuring versatility in system configuration. Each station of the MULTISTATION MANI. is furnished with separate actuator ports A and B, as well as measuring ports MA and MB for precise control and monitoring of hydraulic flow. These actuator ports are conveniently located at the bottom side of the plate for ease of access. The design also includes provisions for mounting NG sandwich plates and valves, which contribute to the manifold's compactness and functionality. Furthermore, this Bosch Rexroth manifold is prepared to accommodate a pressure relief valve type DBD in its pressure line P, enhancing system safety by preventing over-pressurization. Additionally, there is an option to connect a pressure gauge type ABZMM in channel P, allowing operators to accurately monitor system pressure during operation. Overall, this product stands out due to its robust design that enables efficient space utilization while offering flexible control options for various hydraulic systems. Its thoughtful features make it suitable for applications requiring reliable and precise control within a compact assembly footprint.
