MULTISTATION MANI. 2HSR06M-40/01D FE//Z&

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MULTISTATION MANI. 2HSR06M-40/01D FE//Z& (R901475552) is a highly versatile and compact hydraulic manifold designed for ready-for-connection controls in vertical stacking configurations. This product allows for the construction of dense hydraulic control systems by using vertically stackable sandwich plate valves, which can be combined with both on/off and proportional servo valves. Each station within the manifold has access to common pump and tank ports labeled P and T, ensuring streamlined fluid power management across multiple control units. The design features dual pump lines that extend from the front sides of the manifold, providing easy integration into various hydraulic systems. The MULTISTATION MANI. also boasts separate actuator ports A and B at each station, located at the base of the plate for convenient connection to actuators. Additionally, it includes measuring ports MA and MB for monitoring system performance. Preparation for pressure regulation and measurement is integral to this model, as it accommodates the installation of a pressure relief valve type DBD in the pressure line P, alongside a connection point for a pressure gauge type ABZMM to ensure system safety and accuracy. The design facilitates mounting of NG sandwich plates and valves, enhancing its adaptability to different control applications. Overall, this Bosch Rexroth manifold is an efficient solution for creating compact hydraulic controls within industrial applications that require precise fluid power distribution and regulation across multiple operational stations.
