VT-SD-HDX-PLC-000-001-000-000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth VT-SD-HDX-PLC-000-001-000-000 (R901444436) is a state-of-the-art VTHMC Hydraulic Motion Controller designed to offer precise digital control for a variety of hydraulic applications. With integrated axis controller and programming capabilities compliant with IEC standards, this controller provides a broad spectrum of functionalities including position, force, pressure, substitutional (position/pressure and force), and velocity control. It supports multiple operating modes such as valve direct control, drive-controlled position control, drive-controlled positioning, and positioning block operation. Command value presetting can be achieved through bus interfaces XFXF/XF or the analog interface XGXG. Additionally, the device allows for internal PLC program presetting. The VT-SD-HDX-PLC-000-001-000-000 enables independent operation or synchronized control of axes through its axis variant feature. Feedback to the superior control system is facilitated through bus interfaces or an analog/digital interface. For communication with higher-level systems, function blocks are available online for integration. Parameters are set via dual Ethernet interfaces with built-in switch functionality. This controller also boasts comprehensive monitoring functions for error detection, including undervoltage, communication errors, cable breaks, short-circuit monitoring, microcontroller watchdogs, temperature monitoring of integrated electronics, and overcurrent protection. The VTHMC utilizes IndraWorks MLD or DS PC programs for project planning tasks such as parameterization and preparation of PLC programs. A slot for an SD memory card (up to 2 GB capacity) is provided for storing PLC programs and other data; only cards with SPI bus connections are supported. This controller is equipped to handle measurement systems of hydraulic axes including incremental or absolute SSI/Endat sensors as well as analog inputs ranging from 0 to 10 volts or 4 to 20 mA. It comes with a CE mark in compliance with the EMC Directive EC and offers connectivity options like Sercos, EtherNet/IP, PROFINET RT, EtherCAT, PROFIBUS DPV1/V0 & DPV2 & Powerlink ensuring versatile integration into various industrial environments.
