PRESSURE RED.VALVE INTERMEDIATE PLATE Z3DR6VP2-1X/315MSJ3V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z3DR6VP2-1X/315MSJ3V (R901418123) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a predefined setting value. This pilot-operated spool valve, part of the component series X, is notable for its precise pressure adjustment capabilities within a range of bar settings. Its construction includes a sleeve with hexagon for ease of installation and enhanced corrosion protection to ensure longevity in demanding environments. The Z3DR6VP2-1X/315MSJ3V valve is characterized by its flat discharge pressure curves, high stability, and minimal hysteresis, making it ideal for applications where secondary pressure control and reduction are critical. The valve includes a pilot control valve and housing with the main stage, allowing users to set the secondary pressure via an adjustment type. Additionally, the MS version offers the ability to measure and monitor set secondary pressures through a pressure load cell at the measuring port. A distinct feature of this model is its safety mechanism that opens a third line to tank port T if the secondary pressure at actuator port P exceeds the set value. This effectively protects the actuator channel from excessive pressure increases. The Z3DR6VP2-1X/315MSJ3V has multiple ports and supports mechanical actuation. It can accommodate a maximum flow within its size specifications and offers various types of connections including sandwich plate design compatible with NFPA T3.5.1 R2-D03 (CETOP 3) and ISO 4401 porting patterns. This versatile valve supports numerous hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR with FKM seals ensuring compatibility across different systems. Users can benefit from several adjustment options like spindle with internal hexagon or lockable rotary knob with scale for precise control adjustments in industrial settings where accurate pressure regulation is essential.
