MULTISTATION MANI. 6HSR10M-40/01D FE//Z&

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MULTISTATION MANI. 6HSR10M-40/01D FE//Z& (R901287180) is a sophisticated hydraulic manifold designed for creating highly compact hydraulic controls through vertical stacking. This base element enables ready-for-connection controls and allows for the assembly of vertically stackable sandwich plate valves. It supports both on/off and proportional servo valves, providing versatility in application. Each station on this manifold has separate actuator ports A and B, as well as measuring ports MA and MB, ensuring precise control and monitoring of hydraulic systems. These actuator ports are conveniently located at the bottom side of the plate for ease of access. The common pump and tank ports P and T are integrated into the design, with the pump line accessible from both front sides of the manifold. The MULTISTATION MANI. 6HSR10M-40/01D FE//Z& is prepped to receive a pressure relief valve type DBD in its pressure line P, which helps to protect the hydraulic system from overpressure situations. Additionally, there is a provision for connecting a pressure gauge type ABZMM within channel P, offering real-time pressure monitoring capabilities. This manifold's design facilitates the mounting of NG sandwich plates and valves, allowing for a customizable setup based on specific control requirements. Its robust construction ensures reliability in various applications where precise hydraulic control is essential. The Bosch Rexroth MULTISTATION MANI. 6HSR10M-40/01D FE//Z& stands out as an integral component for engineers looking to develop advanced hydraulic solutions with space-saving efficiency and high-performance standards.
