MULTISTATION MANI. 2HSR10M-40/01D FE//Z&

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MULTISTATION MANI. 2HSR10M-40/01D FE//Z& (R901282333) is a meticulously engineered hydraulic manifold designed for vertical stacking applications. It serves as a foundational element for creating highly compact, ready-for-connection control systems. Each station of the manifold allows for the construction of intricate hydraulic controls by utilizing vertically stackable sandwich plate valves in combination with on-off and proportional servo valves. This model boasts a unified pump and tank port P and T, ensuring streamlined connectivity across all stations. The pump line is conveniently accessible from both front sides of the manifold, enhancing ease of use and maintenance. Individual actuator ports A and B are situated at the bottom side of each station's plate, providing separate channels for actuator connectivity. Additionally, measuring ports MA and MB are integrated into the actuator lines to facilitate precise monitoring and adjustments. The MULTISTATION MANI. 2HSR10M-40/01D FE//Z& is prepped to accommodate a pressure relief valve of type DBD within the pressure line P, offering added safety by preventing overpressure scenarios. There's also provision for attaching a pressure gauge type ABZMM in channel P, allowing users to accurately gauge system pressures. With its robust design tailored for mounting NG sandwich plates and valves, this Bosch Rexroth manifold stands out as an essential component in constructing efficient, space-saving hydraulic control systems that demand reliability and precision. Its thoughtful configuration guarantees that it can meet the rigorous demands of various hydraulic applications while maintaining a compact footprint.
