Z1S6D05-4X/N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z1S6D05-4X/N (R901248533) is a direct operated check valve designed for integration into hydraulic systems. This sandwich plate valve is engineered to provide leak-free blocking in one direction while allowing free flow in the opposite, ensuring efficient control of fluid dynamics within a circuit. The valve features a plastic socket that limits the stroke of the poppet and includes an installed spring which aids in the closing movement and maintains the poppet in a closed position when idle, preventing fluid leakage. The Z1S6D05-4X/N offers versatility through its design, which can be utilized both as an angle valve section and as a straight-through valve section. The angle valve section can link or close off up to three internal channels, with stop and sealing functions managed by the plug screw. This allows for flexible configurations within hydraulic systems to meet various operational requirements. Constructed with high-performance plastic for the poppet, this valve ensures perfect leak-tightness and durability against wear. Its corrosion-protected design extends its service life even in demanding environments. The Z1S6D05-4X/N is adaptable to special hydraulic fluids by simply exchanging external seal rings, making it suitable for a wide range of applications. For maintenance considerations, it's important to note that no additional seal ring should be used at the plate side when the blue plastic socket is mounted; however, at the component side, the usual seal ring provides necessary sealing for downstream assembly. The installed plastic socket also serves a sealing function and must not be removed or damaged to maintain integrity. Additionally, this model can be supplied with optional measuring ports and can be requested as a throttle check valve if required by specific system needs. Its porting pattern is compliant with ISO standards, ensuring compatibility with various industry norms and facilitating ease of installation into vertical stackings within hydraulic systems.
