DR6DP2-5X/80YV/60

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP2-5X/80YV/60 (R901139022) is a high-performance, direct operated pressure reducing valve designed for subplate mounting with porting patterns in accordance with DIN form A and ISO standards. This valve is specifically engineered to manage system pressure by limiting the secondary circuit. The secondary pressure can be precisely set through various adjustment types, such as a rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or a rotary knob with scale. In its initial position, the valve permits unrestricted flow of hydraulic fluid from channel P to channel A while simultaneously applying pressure through the control line on the piston area opposite the compression spring. When the pressure in channel A surpasses the preset value on the compression spring, the control spool shifts to maintain a constant level of set pressure in channel A. This mechanism ensures efficient operation even when external forces affect system pressures. The design of this valve allows for internal signal and pilot oil routing via control line from channel A. In case of further pressure increase due to external force on the actuator, it pushes against the compression spring allowing excess hydraulic fluid to discharge into the tank through channel TY. This process prevents significant pressure increases. Leakage oil from the spring chamber is externally discharged through channel TY as well. The optional installation of a check valve facilitates free flow back from channel A to channel P. Additionally, this model includes a pressure gauge connection for monitoring secondary pressure. The Bosch Rexroth DR6DP2-5X/80YV/60 valve boasts impressive specifications such as size component series X, maximum operating pressures up to several hundred bars (exact value not specified), and maximum flow rates measured in liters per minute (exact value not specified). It's designed for robust performance and reliability in hydraulic applications requiring precise secondary pressure regulation.
