THROTTLE CHECK VALVE Z2FS6-2-4X/2QV/62

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z2FS6-2-4X/2QV/62 (R901110659) is a high-performance industrial hydraulic valve designed for reliable throttling of flow to a set value. This direct-actuated valve features a setscrew with lock nut for precise adjustments. It is characterized by its spool symbol configuration, which can be either A A, B B or A A, B B, mechanically actuated for versatile applications. The Z2FS6 valve serves as a twin throttle check valve in sandwich plate design, suitable for both main or pilot flow limitation of one or two actuator ports. Its symmetrical throttle check valves limit flow in one direction while allowing free return flow in the opposite direction. The axial adjustment of the throttle spool via the setscrew enables customization of the throttling point to meet specific requirements. This valve has a maximum pressure tolerance and is part of a specific product group identified by its ID. It features multiple ports and mechanical actuation type, with specifications including maximum flow rate and connection types conforming to Sandwich plate standards. Connection diagrams are available according to NFPA T.. R D SizeCETOP D and ISO standards. The Z2FS6 weighs an exact amount and comes equipped with FKM seals compatible with various hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR. Depending on the installation position, it can be utilized for either supply or discharge throttling. For velocity adjustment through main flow limitation or switching time adjustment via pilot flow limitation, this valve can be installed between directional valves and subplates or between pilot control valves and main valves respectively. It offers different adjustment types including the standard setscrew with lock nut and protective cap; additionally lockable rotary knobs with scales or spindles with internal hexagons are available for precise control. The Bosch Rexroth Z2FS6-2-4X/2QV/62 is designed to integrate seamlessly into industrial hydraulic systems where accurate flow regulation is critical.
