THROTTLE CHECK VALVE Z2FS6B2-4X/1QV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z2FS6B2-4X/1QV (R900438760) is a high-performance industrial hydraulic sandwich plate valve designed for reliable and precise flow throttling to a set value. It is characterized by its direct actuation, fine adjustment capability, and setscrew with lock nut. The valve features two throttle check valves that are symmetrically aligned to limit flows in one direction while allowing free return flow in the opposite direction, making it suitable for both supply throttling and discharge applications. The Z2FS6B2-4X/1QV valve can be used for main or pilot flow limitation of one or two actuator ports. Its mechanical actuation ensures robust control in various industrial settings. For main flow limitation, the valve is typically installed between the directional valve and the subplate; for pilot flow limitation, it is positioned between the pilot control valve and the main valve. This Bosch Rexroth model comes with multiple adjustment types: a setscrew with lock nut and protective cap, a lockable rotary knob with scale, a spindle with internal hexagon and scale, and a rotary knob with scale. The porting pattern adheres to DIN standards, form A, as well as ISO standards with locating hole. The Z2FS6B2-4X/1QV has a maximum operating pressure of up to bar and supports maximum flow rates of l/min. It is compatible with various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR and features FKM seals for enhanced performance durability. The spool symbol B B or B B indicates its configuration options within the system setup. Overall, this Bosch Rexroth hydraulic valve stands out for its versatility in application and precision in controlling fluid dynamics within industrial hydraulic systems.
