4WE6Y6X/BG24NXDZ2/V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6Y6X/BG24NXDZ2/V (R901083168) is a high-performance directional spool valve designed for controlling the start, stop, and direction of fluid flow in hydraulic systems. It features a robust housing, two wet-pin solenoids for actuation, a control spool, and return springs to maintain the spool in its initial position when deenergized. This particular model is direct-operated with solenoid actuation and is suitable for use in potentially explosive atmospheres, adhering to ISO porting pattern standards. The valve operates by shifting the control spool via solenoid force when energized, enabling directional flow between ports P-A and B-T or P-B and A-T. Upon deexcitation, return springs revert the spool to its resting state. An optional manual override allows for movement of the control spool without electrical power. This model does not have a defined spool position in its deenergized state due to the absence of detent. However, it does feature an impulse spool version with detent (Type WE .. XOF... XD), which locks the two spool positions alternately and does not require continuous solenoid energization. Users should note that pressure peaks may cause unintended movements of the control spool; thus, separate return lines or check valves are recommended to avoid such issues. Additionally, if operating conditions generate flows that exceed the valve's performance limit during switching processes, a throttle insert (Type WE ..XXD..B..) must be installed in channel P. The valve's wet-pin DC solenoids are optimized for hydraulic fluid environments and come with an individual electrical connection and cable gland. The subplates for this model are available in an FEZN version as per dimension requirements. Overall, this Bosch Rexroth directional valve offers reliability and precision control in complex hydraulic applications requiring safe operation in hazardous conditions.
