3DR16P6-5X/100Y/00M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3DR16P6-5X/100Y/00M (R900917777) is a sophisticated pressure reducing valve designed to modulate and maintain a predetermined downstream pressure within hydraulic systems. The valve operates as a pilot-operated way pressure reducer with the added function of secondary circuit pressure limitation. Its main components include a control spool and a pilot control valve, which work in tandem to regulate the flow of hydraulic fluid from channel P to channel A, ensuring smooth operation and reliable performance. In its default state, the valve allows unrestricted fluid flow, while simultaneously applying pressure through specific channels to balance against a compression spring. This balance is key to maintaining the set pressure level. When the downstream pressure in channel A exceeds the set value, the control spool shifts to restrict flow until equilibrium is reestablished. The 3DR16P6-5X/100Y/00M valve boasts impressive specifications such as compatibility with subplate mounting and adherence to ISO porting patterns. It offers various adjustment types including rotary knobs and lockable options with protective caps or scales for precise settings. Additionally, it features external pilot oil return via control line at port Y, requiring a depressurized tank connection. This model is engineered for maximum operating pressures of up to bar and can handle maximum flow rates of l/min. The inclusion of a pressure gauge connection allows for monitoring of reduced pressure in channel A, ensuring that system parameters are maintained within desired limits. Overall, this Bosch Rexroth valve is designed for effective reduction from P to A and limitation from A to T of system pressures, making it an essential component for hydraulic systems requiring precise pressure management.
