3DR10P4-6X/100Y/00M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3DR10P4-6X/100Y/00M (R900916657) is a sophisticated pressure reducing valve designed for maintaining a controlled, reduced pressure in hydraulic systems. Its primary function is to regulate system pressure by allowing hydraulic fluid to flow from channel P to channel A without restrictions when in the initial open position. This valve is particularly adept at ensuring the secondary circuit does not exceed a set pressure, thanks to its main valve with control spool and pilot control valve equipped with a pressure adjustment element. The operation of this valve involves balancing the pressures applied to different parts of the device, including the piston area and the spring-loaded side of the control spool. The adjustment of system pressure is achieved through the setting of the compression spring, which determines how much fluid flows through until equilibrium is reached between channel A's pressure and that set by the spring. Should an external force cause an increase in channel A's pressure, the control spool reacts by moving into a closed position, connecting channel A to channel T and allowing excess fluid to discharge into the tank. This model features several adjustment elements such as a rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, and rotary knob with scale for precise control. It also includes a pressure gauge connection for monitoring reduced pressure in channel A. Designed for subplate mounting with porting pattern according to DIN form A, ISO standards, and CETOP RP 121H, it requires separate order subplates. The maximum operating pressure for this component series X is up to bar, while it can handle maximum flow rates measured in liters per minute. The Bosch Rexroth 3DR10P4-6X/100Y/00M provides reliable performance in reducing and limiting system pressures within hydraulic applications.
