THROTTLE CHECK VALVE Z2FS22B8-3X/S

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z2FS22B8-3X/S (R900595835) is a high-performance industrial hydraulic valve designed for reliable flow throttling to a set value. This mechanically actuated sandwich plate valve is part of the ZFS series, which specializes in throttle check valves for flow limitation applications. The model features two symmetrically arranged throttle check valves with adjustable throttle spools that control flows in one direction while allowing free return flow in the opposite direction. The Z2FS22B8-3X/S valve is adept at managing the flow limitation of one or two actuator ports, making it suitable for velocity adjustment of actuators. It operates by directing hydraulic fluid through channel A and throttling point to actuator A, with an adjustable spindle controlling the throttle spool for precise flow regulation. The return flow from actuator B moves the throttle spool, enabling unobstructed flow as a check valve. This model has a size designation of 'B' and can handle a maximum operating pressure of up to bar with a maximum flow rate of l/min. It features a porting pattern that complies with ISO standards and offers versatility in being used for either supply or discharge throttling. The corrosion-protected design ensures durability and longevity in various industrial settings. Furthermore, the Z2FS22B8-3X/S comes equipped with NBR seals compatible with multiple hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. Its connection diagram follows NFPA T.. R D SizeCETOP D standards making it easy to integrate into existing systems. With its robust construction and precision control capabilities, this Bosch Rexroth valve is an essential component for any hydraulic system requiring efficient flow management.
