PRESSURE REDUCING VALVE DR10DP1-4X/150YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP1-4X/150YM (R900500256) is a high-performance industrial hydraulic valve, designed for reliable pressure reduction to a preset value. This direct operated pressure reducing valve is mechanically actuated and comes in a 3-way version, ensuring the limitation of system pressure within secondary circuits. The valve is characterized by its spool symbol P → A and features maximum pressure capabilities that align with its product group specifications. With the ability to handle a variety of hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC, this valve is versatile in its applications. Its seals are made from NBR to ensure durability and resistance against various fluids. The DR10DP1-4X/150YM allows for unobstructed flow from channel B to A in its initial position while maintaining constant pressure levels through an adjustable compression spring mechanism. The unit includes an internal supply of signal and pilot oil via the control line from channel A and accommodates external leakage oil discharge through channel TY. An optional check valve can be installed for free flow back from channel A to B. Additionally, it features a pressure gauge connection for monitoring secondary pressure. Designed for subplate mounting with porting pattern according to DIN Form D and ISO standards, this Bosch Rexroth valve offers various adjustment types including a rotary knob and threaded pin with hexagon and protective cap—both lockable or with scale options. It has been engineered for use within a specified size range denoted by CETOP D standards and can handle maximum operating pressures and flow rates as defined by its component series X designation. The DR10DP1-4X/150YM's robust construction ensures it meets the demands of industrial hydraulic systems where precise pressure control is essential.
