R900912359

DIRECTIONAL SPOOL VALVE 4WE6J6X/EG96NK4/B12

Manufacturer: Bosch Rexroth

Material #: R900912359

Model : 4WE6J6X/EG96NK4/B12


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6J6X/EG96NK4/B12 (R900912359) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction in hydraulic systems. This direct-actuated spool valve features a J spool symbol and operates with solenoid actuation. It is capable of handling a maximum pressure of up to 350 bar and allows for a maximum flow of DC 60 l/min and AC 60 l/min. The valve is equipped with an electrical connection described as Connector pole + PE according to EN 175301-803, ensuring secure and consistent power supply. With its size 6, the valve adheres to the CETOP D03 porting pattern according to ISO 4401, which provides flexibility in installation and maintenance. The high-power solenoid can be optionally rotated by 90 degrees, offering adaptability for different system configurations. Additionally, this model offers single or central electric connections, with an optional auxiliary operating device available. This Bosch Rexroth valve boasts spool position monitoring options and conforms to CE standards as per the LowVoltage Directive (EU) for electrical voltages greater than 50 VAC or 75 VDC. It also meets CSA approval according to CSA C22.2 No. 0 standards. The design includes two switching positions and incorporates NBR seals compatible with various hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. Its robust build ensures durability while maintaining a weight of approximately 1.9 kg. The Bosch Rexroth directional valves are essential components that control the start, stop, and direction of fluid flow within a hydraulic system. They are suitable for various applications requiring precise control of fluid dynamics without spring return or with detent for energy-efficient operation. This particular model offers versatility through its three or four-way version capability and may include additional features such as throttle inserts when required by specific operating conditions to manage flows exceeding the performance limit during switching processes.

$574.00 USD

More are expected on June 17, 2025
  Add to Cart

Status: This product is temporarily out of stock.


This product is eligible for factory repair.
