DZ6DP2-5X/25YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DZ6DP2-5X/25YM (R900425800) is a high-performance, direct-operated pressure sequence valve designed for efficient and reliable hydraulic system operations. This model is adept at connecting a secondary system in a pressure-dependent manner, with the sequencing pressure adjustable through various types of settings. The valve features a compression spring that maintains the control spool in its initial position, ensuring the valve remains blocked until the appropriate pressure level is reached. When the pressure in channel P meets or exceeds the designated value of the compression spring, the control spool shifts, allowing for an unimpeded connection from P to A. This action enables an auxiliary system connected to channel A to engage without experiencing any pressure drop in channel P. The control signal for this operation can be sourced internally from channel P or externally via port B X. The DZ6DP2-5X/25YM offers flexible leakage oil discharge options; it can be configured for external discharge through port T Y or internal discharge via A. It's important to note that when using internal leakage oil discharge, the set cracking pressure will increase according to the pressure present in channel A. This model also provides an optional check valve for facilitating free return flow of hydraulic fluid from channel A back to channel P. Furthermore, it includes a pressure gauge connection that permits monitoring of sequencing pressure directly at the valve. Designed for subplate mounting and compliant with DIN form A standards (without locating hole) and ISO with locating hole specifications, this valve's subplates are available as separate orders. It offers various adjustment types such as a rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, and rotary knob with scale. Optional features include a check valve for added functionality. The DZ6DP2-5X/25YM has a maximum operating pressure of up to several bar and can handle maximum flow rates expressed in liters per minute (l/min), ensuring it meets rigorous operational demands across diverse applications.
