MULTISTATION MANIFOLD 2HSR10-15/01C PHOSPHATED

Manufacturer: Bosch Rexroth

Material #: R900154881

Model : MULTISTATION MANI. 2HSR10-15/01C PHOSPH&

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MULTISTATION MANI. 2HSR10-15/01C PHOSPH (R900154881) is a compact hydraulic control block designed for efficient and reliable operation of valves. This base element is tailored for ready-for-connection controls in a vertical stacking design, allowing for the setup of sandwich plates and valves of size 6. It features separate actuator ports for each station, ensuring precise control over multiple functions. The unit boasts a maximum operating pressure of 315 bar and comes with a durable phosphate coating in accordance with DIN EN ISO standards, which provides corrosion resistance and longevity to the manifold. The port sizes for the pump and return are G1/4, while the connection point is lateral, facilitating ease of installation and maintenance. With dimensions that support a compact form factor, this model allows for numerous vertical stackings, enhancing its adaptability to various hydraulic systems. The MULTISTATION MANI. 2HSR10-15/01C PHOSPH also includes common pump and tank lines that simplify the hydraulic circuitry by reducing the number of connections required. This product is compatible with HLP hydraulic fluid, which is widely used in industry due to its excellent lubrication properties and thermal stability. Weighing in at just 0.9 kg, it provides a lightweight yet robust solution for hydraulic control applications. In summary, the Bosch Rexroth MULTISTATION MANI. 2HSR10-15/01C PHOSPH offers a versatile and efficient solution for controlling hydraulic valves within complex systems while maintaining compactness and durability through its thoughtful design features and quality construction materials.

$542.82 USD

More are expected on March 20, 2025

Add to Cart

Status: This product is temporarily out of stock.

Qty: Delivered as early as March 20, 2025 when ordered in

MULTISTATION MANIFOLD 2HSR10-15/01C PHOSPHATED

Size 10, 2 valves

Compact hydraulic controls for 2 valves of size 10

Unpacked Weight: 8.16 kg

Base element for ready-for-connection controls in vertical stacking design Compact hydraulic controls Common pump line Common tank line Separate actuator ports of the stations Measuring ports in the actuator lines, optional Set-up of sandwich plates and valves of size 10 Mounting of sandwich plates and valves of size 6 with additional adapter plate possible

Separate actuator ports of the stations
Base element for ready-for-connection controls in vertical stacking design
Compacter hydraulic control block
Common pump and tank line
Size 10
Maximum operating pressure 315 bar

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Max. pressure	315
Surface coating	Phosphate coating DIN EN 12476
Port sizes pump and return	G3/4
Productgroup ID	9,10,11,12,13,14
Connection point	lateral
Size	10
Length	157
Number of vertical stackings	2
Port size	G1/2
Weight	8.16
Hydraulic fluid	HLP

Manifold	01	02	03		04		05	06	07	08
		HSR	10	‒		/	01

Number of ready-for-connection controls in vertical stacking design
01	1 Control	1
	2 controls	2
	3 Controls	3
	4 controls	4
	5 controls	5
	6 controls	6
	7 controls	7
	8 controls	8
02	Manifold	HSR
03	Size 10	10
Component series
04	Port size: A, B = G1/2; P, T = G3/4	15
04	With enlarged connection thread; port size: A, B = G3/4; P, T = G1	35
Connection thread
05	Pipe thread according to ISO 228/1	01
Position of actuator ports
06	Lateral	C
06	At the bottom	D
Version
07	Standard version	no code
07	With measuring ports in A and B	S08 1)
Coating
08	Phosphate coating according to DIN EN 12476	PHOSPHATED 2)
08	Galvanic coating DIN 50979	FE//ZN8//CN/T0
1) Not possible with component series 25 with lateral actuator ports
2) Standard version (manganese or zinc phosphate coating)

Size		10
Material		GGG40
Surface coating		Standard coating: Phosphate coating according to DIN EN 12476 with after-treatment (greases, oils, lubricants)
Operating pressure max. 1)	bar	315

1)	Manifold without valve fitting

For applications outside these parameters, please consult us!
