PROXIMITY SWITCH BES517-399-NO-C-03

Manufacturer: Bosch Rexroth

Material #: R345304004

Model : PROXIMITY SWITCH BES517-399-NO-C-03

$116.64 USD

More are expected on October 30, 2024

Add to Cart

Status: This product is temporarily out of stock.

Qty: Delivered as early as October 30, 2024 when ordered in

PROXIMITY SWITCH BES517-399-NO-C-03

Unpacked Weight: 0.0595 kg

3D CAD	Download 3D CAD
3D CAD	Download 3D CAD

Weight0.0595Functional principleinductiveFootnote cable cross-sectionTechnical data only for the cast-on connection line at the proximity sensor. Even more performance, e.g. extension cables are offered for use in an energy chain.UseReference switchFunction indicatoryes

Technische Daten

Part number		R345304001	R345304003	R345304002	R345304004
Functional principle		inductive
Operating voltage (min ... max)		10 V DC ... 30 V DC
Load current	mA	≤ 200
Switching function		PNP/normally closed (NC)	PNP/normally open (NO)	NPN/normally closed (NC)	NPN/normally open (NO)
Connection type		Line 3 m, 3-pin, free line end
Function indication		✓
Short-circuit protection		✓
Reverse polarity protection		✓
Switching frequency	kHz	2.5
Maximum permissible starting speed		depending on the switch tab
Suitable for flexing installation 1)		‒
Can withstand torsion 1)		‒
Weld spark resistant 1)		‒
Cable cross-section 1)	mm2	3x0,14
Cable diameter D 1)		3.5 mm ±0.15
Bending radius, stationary 1)	mm	12
Bending radius, flexing 1)	mm	12
Bending cycles 1)		‒
Permissible ambient temperature (min ... max)		-40 °C ... +70 °C
Protection type		IP65
MTTFd (as per EN ISO 13849-1 )	yrs	830		585

1)	Technical data only for the cast-on connection line at the proximity sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain.
