LOCATING RING D=9 ...
Manufacturer: Bosch Rexroth
Material #: R039660544
Model : LOCATING RING D=9 &
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LOCATING RING (R039660544) is a precision-engineered mechanical accessory specifically designed for linear axes applications. This centering ring falls under the product group ID of mechanical accessories and is categorized as a centering ring, which is instrumental in ensuring accurate positioning and positive locking when mounting customer attachments to the frame.
Constructed from high-quality steel, this locating ring guarantees durability and reliability in various industrial settings. The outer diameter of the ring is denoted as D=9, which indicates its size compatibility with corresponding equipment. The weight and size C are tailored to maintain the balance and integrity of the connection, while the tolerance D prefixprefix.suffixsuffix ensures that the ring fits precisely with minimal deviation, thereby providing a secure fit.
The nominal size and size H specifications are critical for ensuring that this locating ring can be integrated seamlessly into existing systems without requiring extensive modifications. Its primary function is to create a positive-locking connection with excellent reproducibility, which is essential for maintaining consistent performance during repetitive processes.
In summary, the Bosch Rexroth LOCATING RING (R039660544) is an indispensable component for users requiring precise alignment and secure attachment in their linear motion systems, offering both robust construction and precise manufacturing tolerances to ensure optimal functionality in demanding applications.
$5.43 USD
Availability: 322 In Stock
Available for immediate shipmentQty: Delivered as early as September 10, 2024 when ordered in
