BALL NUT ZEV-E-S 16X5RX3-3

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZEV-E-S 16X5RX3-3 (R254200005) is a high-precision ball screw assembly designed for linear motion applications. This screw-in nut features a nominal diameter of 16 mm and a lead of 5 mm, with a right-hand thread direction ensuring compatibility with specific motion control setups. The ZEV-E-S series is part of the standard series offered by Bosch Rexroth, known for its reliability and performance. This particular model comes equipped with a low-friction seal and standard axial clearance, optimizing it for smooth operation and reduced resistance. The ball screw nut has been designed with Rexroth connection dimensions, allowing for seamless integration into existing systems. The product is characterized by its dynamic load capacity and static load rating, which have been calculated based on tolerance grades T3 and T7; these values are only valid for these grades, and any other grade should consider the correction factor as detailed in the technical notes. The ZEV-E-S 16X5RX3-3 operates within a temperature range from a minimum bearing temperature to a maximum permissible linear speed. It can withstand continuous operating temperatures up to certain degrees Celsius while managing temporary peaks at higher temperatures without compromising functionality or longevity. These temperature measurements are taken on the outer shell of the nut to ensure accuracy. Additionally, this ball screw assembly boasts an impressive dynamic load capacity, which along with its static load rating ensures that it can handle significant loads without failure. Its construction adheres to Category B standards, providing assurance of quality and durability in demanding applications. With a weight that reflects its robust build yet efficient design, the Bosch Rexroth ZEV-E-S 16X5RX3-3 screw-in nut is an essential component for precision-driven systems requiring reliable linear movement. Its technical specifications ensure that it meets the rigorous demands of various industrial applications while maintaining Bosch Rexroth's reputation for excellence in engineering components.
