BALL NUT ZEM-E-S 16X5RX3-4

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZEM-E-S 16X5RX3-4 (R151201022) is a high-precision ball screw assembly designed for linear motion applications requiring smooth and accurate movement. This cylindrical single nut ZEMES features a nominal diameter of 16 mm, a lead of 5 mm with a right-hand thread direction, and is equipped with standard seals and standard axial clearance to ensure reliable operation under various conditions. It is part of the standard series in Rexroth's product lineup and comes with a tolerance grade T, which applies to the sizes as per the product overview for screws. The ZEM-E-S 16X5RX3-4 has been engineered with multiple ball track turns to distribute the load evenly, enhancing its dynamic load capacity. The nut type is specifically designed for use with ball screw assemblies, ensuring compatibility and optimal performance when paired with corresponding screw drives. Its construction allows for a maximum operating temperature range from -10°C to +80°C, accommodating various environmental conditions without compromising functionality. With its robust design, this ball screw assembly can handle continuous operation at temperatures up to 80°C and tolerate temporary peaks up to 100°C when measured on the outer shell of the nut. The static load rating and dynamic load capacity are validated for tolerance grades T3 and T5; however, users should consider the correction factor f_a_c when dealing with other tolerance grades. This component exhibits a maximum permissible linear speed (v_max) that supports efficient movement within mechanical systems. Its critical speed n_cr and characteristic speed d_n are detailed in Rexroth's general technical notes, which are essential for project planning to ensure safe and effective application. Weighing in at approximately 0.3 kg, this model maintains a compact footprint without sacrificing performance or durability. The Bosch Rexroth ZEM-E-S 16X5RX3-4 ball screw assembly is an integral component suitable for various applications where precise linear motion is required.
