ROLLER RUNNER BLOCK CARBON STEEL RWD-055-SLS-C2-U-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-055-SLS-C2-U-2 (R18235292X) is a high-precision roller runner block designed for linear motion applications requiring extreme accuracy and rigidity. This model is part of the RSHP series, which is known for its versatility in various installation, environmental, and operating conditions. The RWD-055-SLS-C2-U-2 features a slimline width, long length, and standard height format (SLS), with a runner block body constructed from unalloyed steel CS. It offers an ultra precision accuracy class (UP) and comes with a medium preload class C. The product is characterized by its ability to handle high torque loads and maintain maximum rigidity in all directions due to additional screw connections on two bore holes at the center. It boasts unrestricted interchangeability, allowing it to be combined with any guide rail version within its series. The innovative channel design ensures minimum lubrication quantities are needed while providing smooth, quiet operation through optimally designed return and guideways for rollers. Accessories can be easily attached to the roller runner block from both above and below, enhancing its functionality. The integrated all-around sealing comes as standard for added protection against contaminants. This model has been engineered with an optimized entry zone geometry and a high number of rollers per track to minimize elastic deflection variation and achieve the highest precision in travel accuracy. Intended for use in various profiled rail systems—specifically sizes A, B, E, H, K, N, S, T, and V—the RWD-055-SLS-C2-U-2 maintains its preload even under operational load conditions. Its dynamic load capacity C and dynamic torsional moment load capacity Mt are determined based on a 100 km travel as per DIN ISO standards. For ease of maintenance, lube nipples are possible on all sides of the unit. This Bosch Rexroth roller runner block does not come with initial lubrication or attachment elements but is preserved for longevity. Its straightforward design allows it to be slid onto rails effortlessly while ensuring top-tier performance in precision applications without necessitating special designs for typical uses.
