ROLLER RUNNER BLOCK CARBON STEEL RWD-055-SLS-C2-S-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-055-SLS-C2-S-2 (R18235212X) is a high-precision roller runner block designed for linear motion applications requiring super precision and medium preload. This product is part of the RSHP series, characterized by a slimline width, long length, and standard height, which makes it suitable for various installation conditions without the need for special designs. The runner block body is crafted from unalloyed steel CS and adheres to the accuracy class SP (super precision), ensuring minimal elastic deflection and maximum precision during operation. The model features an overall length of . mm and can be used interchangeably with guide rails of every accuracy level. It boasts high load ratings in all four main directions, providing maximum rigidity due to additional screw connections on two bore holes in the center of the block. The innovative channel design ensures minimum lubrication quantities are required while allowing smooth and quiet operation due to optimally designed return and guideways for the rollers. Moreover, this runner block has integrated all-around sealing as standard and allows for easy maintenance with lube nipples on all sides. It does not come with an initial lubrication or attachment elements on either front reference edge but includes a straight lube connection loosely attached. Attachments can be mounted from both above and below the block, further enhancing its versatility. This product is specifically tailored to meet DIN ISO standards for dynamic load capacity C, static longitudinal moment load capacity ML, dynamic torsional moment load capacity Mt, friction force, friction coefficient, permissible ambient temperature ranges, acceleration amax, preload force requirements during operation under load, maximum permissible linear speed vmax, seal type DS (double-lip seal), material specifications (carbon steel), nominal size specifications for profiled rail systems (size H), rail separation requirements for Roller Guide Rail systems (size T), thread diameter specifications (M size S), weight considerations (. kg nominal size), and overall travel accuracy. These detailed specifications ensure that users can select this linear guide confidently according to DIN standards for their specific application needs.
