BALL RUNNER BLOCK CARBON STEEL KWD-030-FKS-C0-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FKS-C0-H-1 (R166579320) is a state-of-the-art ball runner block designed for high-precision and low-friction linear movement. This runner block is part of the CS series, which is known for its robust construction and reliable performance. It features a high accuracy class H, indicating that it is crafted for applications requiring exceptional precision. The product is preload-free (preload class C), ensuring smooth motion without initial tension in the system. Constructed from unalloyed steel CS, the runner block body offers durability and longevity. It has a size designation that fits specific application requirements and comes with an initial lubrication and preservation, reducing maintenance needs over time. The roller bearing grease Dynalub included with the product enhances its performance under various conditions. This model does not include a ball chain and allows for attachments to be mounted from both above and below the runner block, offering flexibility in design configurations. The B.RUNNER BLOCK CS KWD-030-FKS-C0-H-1 boasts a straight lube connection that is loosely attached, facilitating easy maintenance. With integrated all-around sealing, the runner block ensures protection against contaminants such as dirt, chips, and coolants, thereby extending its service life. Its design permits long-term lubrication over several years without frequent re-lubrication needs. Additionally, it can withstand high torque loads while maintaining high rigidity in all load directions. This product can be used interchangeably with guide rails of every accuracy level within its series. It supports maximum precision due to its patented entry zone which increases travel accuracy significantly. Furthermore, it's capable of enduring high acceleration rates and operates efficiently within a permissible ambient temperature range. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FKS-C0-H-1 is an advanced linear guide component ideal for applications where space constraints exist in the longitudinal direction and where ultimate precision is paramount. Its robust design allows it to deliver excellent dynamic characteristics while ensuring maximum system rigidity when used in various industrial settings.
