BALL RUNNER BLOCK CARBON STEEL KWD-030-FKS-C1-H-1
Manufacturer: Bosch Rexroth
Material #: R166571323
Model : B.RUNNER BLOCK CS KWD-030-FKS-C1-H-1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FKS-C1-H-1 (R166571323) is a high-precision ball runner block designed for linear motion applications. It features a size 30 flange, short length, and standard height format FKS. The runner block body is constructed from unalloyed steel CS, ensuring strength and durability. It comes with a low preload class C and high accuracy class H, providing excellent travel accuracy and system rigidity. The ball chain integrated into the design contributes to a low noise level and smooth travel behavior.
This runner block boasts an initial lubrication and preservation for long-term maintenance-free operation, with the option of several years of lubrication without the need for reapplication. Its roller bearing grease Dynalub enhances performance and longevity. Designed without attachment elements on the left or right front reference edges, it offers flexibility in mounting attachments from above or below. The straight lube connection is loosely attached for ease of maintenance.
With its ability to self-align, this runner block compensates for misalignments in the system, ensuring consistent performance even in challenging conditions. The product also features integrated all-around sealing to protect against contaminants such as dust and liquids, thereby extending its service life.
Its dynamic characteristics are optimized for high-speed applications with excellent dynamic load capacity (C), static load rating (C0), dynamic torsional moment load capacity (Mt), and static longitudinal moment load capacity (ML). The B.RUNNER BLOCK CS can handle high torque loads and offers high rigidity in all load directions, allowing it to be used with just one runner block per rail if necessary.
This product is interchangeable with guide rails across various accuracy classes, making it versatile for different installation requirements. Optional features include an integrated inductive measuring system that provides wear-free operation without affecting dynamics.
Overall, the Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FKS-C1-H-1 offers maximum precision and reliability for demanding linear motion applications where space is limited or where significantly reduced frictional oscillations are required under external loads.
$215.67 USD
More are expected on February 24, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 24, 2025 when ordered in
