BALL RUNNER BLOCK CARBON STEEL KWD-030-FLS-C1-U-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FLS-C1-U-1 (R16537192Y) is a state-of-the-art linear motion rolling guide designed for ultra-precise applications. It features a size 30 flanged long standard-height runner block made from unalloyed steel CS, ensuring durability and high performance. The runner block boasts an ultra precision accuracy class (UP) and is equipped with a ball chain mechanism that provides low noise operation and optimal travel behavior. With a low preload class C, the B.RUNNER BLOCK CS ensures smooth movement and reduced frictional oscillations, especially under external loads. This model is prelubricated with roller bearing grease Dynalub for maintenance-free operation over several years and comes with metal thread lube fittings for easy lubrication access. It does not include attachment elements but offers end-face fastening threads for versatile mounting options. The runner block's integrated all-around sealing protects against contaminants, extending its service life. With high rigidity in all load directions, this runner block can be used with just one per rail in certain applications, improving system rigidity thanks to its preloaded O-arrangement and additional mounting screw holes at the center for better load distribution. It also has the capability to integrate an optional inductive measuring system without any wear concerns. The B.RUNNER BLOCK CS KWD-030-FLS-C1-U-1 is compatible with all SNS/SNO ball guide rails from Bosch Rexroth and can handle high load ratings in all four main loading directions. It's designed to meet the most demanding rigidity requirements while offering maximum precision and dynamic characteristics suitable for various linear motion applications.
